T.I.T.S. Sit 820-652 Gas Valve (Natural Gas)
Product details
| Management number | 211661657 | Release Date | 2026/04/04 | List Price | $66.00 | Model Number | 211661657 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
0820652 Split-system millivolt control natural gas valve for use in vented appliances.**** HI/LO burner adjustment with manually operated knob**** Minimum voltage 145mV Coil resistance 2.25±0.5**** Thermo-Electric Unit Hold-in current less than 285Ma Drop-out current Greater than 125mA with coil resistance 0.018± 0.003**** Gas type Natural Gas HI/LO action Manual Pressure set-point 3.5” w.c. ± 0.3**** Range of adjustment 3.5” w.c. -1.6” w.c. Set at 30K btu/hr**** Thermocouple connection 11/32 ASA-DNC**** Natural Gas Inlet 3/8 in. NPT**** Natural Gas Outlet 3/8 in. NPT**** Maximum natural gas inlet pressure 1/2 PSIG Ambient operating**** temperature 32° to 175° F**** Maximum @ 1 in. w.c. pressure drop 100,000 BTU per hour**** Regulation capacity 5,000 to 195,000 BTU AP per hour*****
- Quick drop out for safety
- Hi-Lo Adjustment
- This valve is also used for Monessen or Majestic products
- The Sit 820652 Control Valve will replace the following models of Gas Valves by SIT Controls: Model 820.654 - 820.644 - 820.652 - 820.635 - 820.655 - 820.662 - 820.952
- Due to the nature of this product, we cannot accept returns. All sales are final.
| UPC | 686751138638 |
|---|---|
| Size | 0.375 inches |
| Brand Name | SIT Strings |
| Unit Count | 1.0 Count |
| Valve Type | Gas Valve |
| Thread Size | 3/8 inches |
| Thread Type | NPT |
| Manufacturer | SIT |
| Model Number | 820-652 |
| Material Type | Natural Gas |
| Exterior Finish | Stainless Steel |
| Number of Ports | 2 |
| Maximum Pressure | 100932.55 Pascal |
| Specification Met | ASME, ANSI, CSA, UL, ASTM |
| Inlet Connection Size | 0.38 Inches |
| Inlet Connection Type | National Pipe Tapered |
| Outlet Connection Size | 0.38 Inches |
| Outlet Connection Type | NPS |
